Magnatex Magnetic Drive Centrifugal Pumps

The efficient and dependable choice for medium-flow, medium or high head applications.

Call for pricing
Part Number
  • MMDCP
Manufactured
Availability
  • Call for availability

Features

  • Pump models in this series include:
    • MAXP= Max flow: 2000 GPM/Max head: 470 feet
    • MPL= Max flow: 340 GPM/Max head: 400 feet
    • MP= Max flow: 150 GPM/Max head: 190 feet
    • MHL= Max Flow: 300 GPM/Max head: 400 feet
    • MPT= Max flow: 40 GPM/Max head: 440 feet
    • MMP= Max flow: 20 GPM/Max head: 95 feet
    • MEP= Max flow: 108 GPM/Max head: 103 feet
    • MMP= Max flow: 20 GPM/Max head: 95 feet
    • ME= Max flow: 90 GPM/Max head: 140 feet
    • SM= Max flow: 30 GPM/Max head: 110 feet
  • See datasheet for further details

The Magnatex Magnetic Drive Centrifugal Pumps are the efficient and dependable choice for medium-flow, medium to high head applications. Pumps' process side conforms to ANSI B73.3 dimensions. Magnatex pumps feature sub-ANSI sizes for efficient lower flow applications. Affordable, top-performing Magnatex pumps give you higher efficiency with lower horsepower and lower total cost of ownership.

The main advantage of a magnetic drive centrifugal pump is that it eliminates the need for a traditional shaft seal, which is a common point of failure in conventional pumps. Since there are no shaft seals, the pump becomes completely sealed, preventing any leakage of the pumped fluid. This makes magnetic drive centrifugal pumps ideal for handling corrosive, toxic, or expensive fluids that need to be contained.
